IP65 120WLASER MOVING

POWER SYSTEM

• Voltage: AC110-240V, 50/ 60Hz
• Power：160W

OPTICAL SYSTEM

• Light Source: 120W Laser Engine + 36pcs 0.5W RGB 3in1 LED
  Light source life: 20000 hours
• LEN Diameter: 126mm
• Beam Angle: 1.2°
• Frost: 0-100% linear Frost

DYNAMIC EFFECT

• Color 1:15 colors + Open
• Color 2: CMY Color Mixing
• Static Gobo: 29 static Gobos + Open
• Prism: 6-linear Prism and 8-facet Prism with bi-directional rotation at variable speed
• Strobe: shutter speed adjustable from 1-25Hz
• LED Frequency: 600Hz-24,000Hz Adjustable

CONTROL SYSTEM

• Pan/Tilt: 360° endless pan & tilt movement, 16 bit smooth and precise resolution for PAN/TILT movement
• Control Mode: DMX 512, Master/Slave, Work Auto, Sound Activated, Support RDM control
• DMX Channels: 33/41 DMX Channels
• DMX Connector: 3-PIN IP XLR IN/OUT

BODY FEATURE

• Housing: Aluminum Alloy Diecast + plastic
• Working Environment: -20℃~ 45℃
• IP Rate: IP65 waterproof grade design
• Product Size: 280x268x429mm
• Packing Size: 545x375x380mm
• Net weight: 16.95kgs
• Gross weight: 18.90kgs
