POWER SYSTEM
Voltage: AC 110-240V; 50/60Hz
Power: 935W
Lifespan：20,000 hours
Power connectors:IP65 Power head input
OPTICAL SYSTEM
LED Source: 5×120W RGBL LED, 24 pieces of 3535 LED beads for auxiliary light on the outer circle of the lamp head, light source
Light beam angle: 3°-30°
Spot angle: 4°-35°.
Dimmer: 0%~100% smooth dimming
Strobe : 0-25Hz/S
CONTROL SYSTEM
Pan: 540°+16bit fine
Tilt: 250°+16bit fine
DMX channel mode: 41CH/71CH, can be upgraded through DMX connection software
Control protocol: DMX512, RDM, Artnet (optional)
Display screen: LCD display screen
X-axis rotation angle: 60°, Y-axis rotation: 220°. The main light source adopts 5 independent lamp heads
The outer circle of the lamp head uses 24 pieces of color LED, which can be independently controlled and seamlessly spliced
DYNAMIC EFFECTS
Main features:
4 selectable dimming curves
Linear CTO color temperature adjustment, excellent color mixing function, linear zoom function
BODY FEATURE
Housing: magnesium alloy
Fixture dimension: 1002mmx156mmx312mm
NW: 35 Kg
